Adsorption Dehumidifiers
The adsorption dehumidifiers using a technology based on the use of materials naturally drying (ie endowed with high physical-chemical affinity towards water vapor), as the silica gel.
This operation technology makes them suitable for use in environments where they are required humidity values even at low temperatures and constant values dew point very low (up to -60°C). With this technique it is possible to dehumidify dehumidification any type of environment in any condition.
TFT Dry Air Solutions has developed the line AD (Air Dry) to respond to the need for dehumidification to extreme temperatures (below 0°C) and very low humidity values. The dehumidifiers in this line are particularly suitable for continuous operation stationary and mobile. To limit the energy consumption resulting TFT proposes integrative solutions as the Heat Recovery Systems capable of recovering up to 60% of the heat generated by the machine to re-enter the cycle of operation, generating a considerable saving.
Request information
For more information about our products or to request a quote, please fill out the form below.
Our absorption dehumidifiers products
Learn about the features of our models and download the dedicated pdf.
ADC200E
- Moisture removal capacity = 1,09Kg/h
- Process air flow rate = 250m3/h
- Power consumption = 1,72KW
- Supplied modules = None
ADS150/250/450
- Moisture removal capacity = 0.47Kg/h to 1.62Kg/h
- Process air flow rate = 150m3/h to 450m3/h
- Power consumption = 0.78KW to 1.56KW
- Supplied modules = None
AD270/2200
- Moisture removal capacity = 0.99Kg/h to 14.1Kg/h
- Process air flow rate = 270m3/h to 2200m3/h
- Power consumption = 1.97KW to 21.03KW
- Supplied modules = Heat recovery
AD800/1100
- Moisture removal capacity = 4.8Kg/h to 5.0Kg/h
- Process air flow rate = 800m3/h to 1100m3/h
- Power consumption = 7.0KW to 7.1KW
- Supplied modules = Air condensation, heat recovery. pre/post cooling and heating
AD1000/3100
- Moisture removal capacity = 8.8Kg/h to 18.9Kg/h
- Process air flow rate = 1000m3/h to 3100m3/h
- Power consumption = 12.6KW to 29.0KW
- Supplied modules = Air condensation, heat recovery. pre/post cooling and heating
AD3000/6500
- Moisture removal capacity = 23.0Kg/h to 32.7Kg/h
- Process air flow rate = 3000m3/h to 6500m3/h
- Power consumption = 32.3KW to 57.5KW
- Supplied modules = Air condensation, heat recovery. pre/post cooling and heating
AD7000/25000
- Moisture removal capacity = 52.9Kg/h to 162.0Kg/h
- Process air flow rate = 7000m3/h to 25000m3/h
- Power consumption = 81.4KW to 272.7KW
- Supplied modules = Heat recovery, pre/post cooling and heating
ADP2000/12000
- Moisture removal capacity = 18.6Kg/h to 94.9Kg/h
- Process air flow rate = 2000m3/h to 12000m3/h
- Power consumption = 27.4KW to 103.7KW
- Supplied modules = Purge low DewPoint, heat recovery, pre/post cooling and heating
